The Electronic Section
The Electronic Section
Electronic meters used are easily visible from across the room with no moving parts to wear out. GFI circuit breaker protection for maximum safety. Fuse protection: 3A system, 3A 12V section, 2A 6V section, 2A 117V section, 1A for each valve. Time sequence relay controls 12V, not 110V for greater reliability. Valve solenoids are driven by independently fused, solid-state, zero-crossing relays. Bright panel lamps can easily be seen in well lit areas without generating excess heat. Interior components are printed circuit board mounted. Plug-in modules allow easy replacement and upgrade.
